30 SMD3020 Super bright LED light step wall lights, ip67 ce and rohs led step wall lights, RGBY smd super bright led step wall lights, led lights-comlite led limited
Specifications:
|
Housing:
|
12# die-casting aluminum RAL9007 grey powder coated T=60-80um Adhesion of ISO class 1/ASTM class 4B
|
|
Front cover:
|
316# stainless steel
|
|
Glass:
|
Tempered glass T=4mm
|
|
Waterproof cable gland:
|
IP-67 copper and nickel coated
|
|
Waterproof seal:
|
Molding shaped double silicone seal
|
|
LED:
|
21pcs SMD 3020 LEDs
|
|
Driver:
|
constant current output
|
|
Operating temperature:
|
0℃-40℃
|
|
Power cable:
|
H05RN-F 3X0.75m㎡ L=0.5m
|
|
Mounting sleeve:
|
PVC
|
Technique Parameters:
| Part No. |
Light Source |
Lens Beam Angle(°) |
Input (V) |
Typical Current(mA) |
Typical Consumption(w) |
| D1I3007 |
30XSMD
3020 |
120 |
120vac
240vac |
43
30 |
2.8
3.2 |
Advantage:
1. Beautiful appearance design
2. Long lifespan .
3. Green Light, environmental protection
4. Low power consumption, high efficiency, economic
5. Single color White, Warm White, R, G, B, Y, Purple are available
6. CE and RoHS approval, IP65
